1. Reading motor markings

2207, 2306 and 1404 describe stator size in millimetres: the first two digits are diameter and the last two are height.

22diameter, mm07height, mmKVRPM per volt

2207

A taller stator gives more torque and a fast throttle response. It suits aggressive freestyle and heavier 5-inch builds.

2306

A wider, shorter stator can feel smoother at low and mid RPM and is common for racing and light freestyle.

2. What KV means

KV is approximate unloaded RPM per volt. It is not a power rating: propeller, voltage, current and weight change the real result.

4S: 2400-2750KV for 5 inchLively response with about 14.8 V nominal battery voltage, but more current and heat.
6S: 1700-1950KV for 5 inchHigher voltage with lower KV, often improving efficiency and reducing sag around 22.2 V nominal.
Rule: higher battery voltage needs lower motor KV. Check the motor specifications before using 6S.

3. Frame, motor and battery compatibility

ClassFrame / propMotorsKV guide
Tiny Whoop65-75 mm, 1.2-1.6 inch0802, 1102, 110318000-25000, 1S
Toothpick2-3 inch1204, 1404, 15053500-4500, 3S-4S
Cinewhoop3 inch with ducts2004, 2203.52700-3000, 4S
Standard FPV5 inch2207, 23062400-2500, 4S or 1750-1950, 6S
Long range7-8 inch2807, 2810, 31101200-1500, 6S

4. Motor construction

Shaft and mount

M5 is a threaded shaft with a nut for 5-inch and larger builds. T-mount uses two M2 screws and is common on 1.5-3 inch builds.

Magnets and bearings

N52/N52H describe magnets. Good bearings reduce play, noise and vibration. Bell play is a mechanical problem, not only a PID problem.

BrotherHobby GOM 2207 1750KV motor
2207 1750KV: 6S thrust
T-Motor Velox V2207 V2 1750KV motor
2207 1750KV: practical freestyle

5. Mounting and maintenance

  1. Check screw length. A screw that is too long can touch the copper windings and damage the ESC.
  2. Use blue threadlocker sparingly. Keep it on the metal part of the screw and away from motor internals.
  3. Do not overtighten. The frame must not crack and the bell must spin freely.
  4. Clean after a crash. Open motors attract metal sand; blow them out and check for play before arming.

6. First-flight checklist

  • All four motors are the same model or a compatible set.
  • KV matches battery voltage and propeller.
  • The ESC has current headroom and supports the cell count.
  • Screws do not reach the windings.
  • Motor direction was checked without props.
  • The first power-up used a smoke stopper.
  • Short tests show no abnormal heat, noise or vibration.
Do not compare KV alone. The correct system is motor + propeller + battery + weight. Check the complete combination in the builder.
